Brilliance, brightness and versatility: 3 words to define the power of this LED color projector (RGBAW + UV)!
Wash FX Hex offers a wash effect and a blinder. Its 6 tracking zones can be used for a dazzling wash effect: with the advanced master/slave function, it is all the projectors that harmonize for the most beautiful effects.
Multiple control options include stand-alone, DMX and IR - Wash FX Hex is compatible with an optional IRC-6 wireless remote control. Save time and wiring with the ability to chain multiple units together. Optimal storage in the CHS-40 VIP carry bag.
Bottom line:
- Versatile effect light works as a chaser, wash or blinder
- Generate a wide color spectrum and achieve natural-looking color temperatures with its Hex color LEDs
- Advanced master/slave function: sequence tracking on all fixtures
- Wash, Blinder or 6-zone light
- Multiple control options include stand-alone, DMX, IR, or master/slave
- Compatible with optional IRC6 wireless remote control
- Power supply saves wiring time
- Fits ideally in the CHS-40 VIP equipment bag
Technical specifications :
- DMX channels: 3, 6, 11 or 40
- DMX connectors: XLR 3-pin
- Light source: 18 LEDs (hex-color RGBAW+UV) 8 W, 2.8 A, 50,000 hours life expectancy
- Strobe frequency: 0 to 24 Hz
- PWM frequency: 1.14kHz
- Beam angle: 41
- Field angle: 68
- Illuminance: 2422 lux at 2 m
- Electrical connection: 3 units at 120 V; 5 units at 230 V
- Input voltage: 100 to 240 VAC, 50/60 Hz (automatic regulation)
- Power and current: 200 W, 2.5 A at 120 V, 60 Hz
- 194 W, 1.5 A at 230 V, 50 Hz
- Weight: 3.2 kg (7.0 lbs)
- Dimensions: 11.2 x 6.3 x 13 in (285 x 160 x 330 mm)
- Approvals: CE
- Optional controllers: IRC-6
Includes:
- Wash FX Hex
- Power cable
- Quick reference guide
